Siemens PM240-2

Technical data
7.3 Technical data, 200 V inverters
Power Module PM240-2
Hardware Installation Manual, 12/2015, A5E33294624B AD
75
Table 7- 9 PM240-2, IP20, FSD, 3 AC 200 V … 240 V
Article No. - without filter
6SL3210-…
…1PC24-2UL0
…1PC25-4UL0
…1PC26-8UL0
LO base load power
LO base load input current
LO base load output current
11 kW
40 A
42 A
15 kW
51 A
54 A
18.5 kW
64 A
68 A
HO base load power
HO base load input current
HO base load output current
7.5 kW
36 A
35 A
11 kW
43 A
42 A
15 kW
56 A
54 A
Siemens fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NE1818-0 / 63A
60 A
3NE1 820-0 / 80A
70 A
3NE1 021-0 / 100A
90 A
Power loss
0.42 kW
0.57 kW
0.76 kW
Required cooling air flow
55 l/s
55 l/s
55 l/s
Weight
17 kg
17 kg
17 kg
Table 7- 10 PM240-2, IP20, FSE, 3 AC 200 V … 240 V
Article No. - without filter
6SL3210-…
…1PC28-8UL0
…1PC31-1UL0
LO base load power
LO base load input current
LO base load output current
22 kW
76 A
80 A
30 kW
98 A
104 A
HO base load power
HO base load input current
HO base load output current
18.5 kW
71 A
68 A
22 kW
83 A
80 A
Siemens fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3 NE1 021-0 / 100A
100 A
3 NE1 224-0 / 160A
150 A
Power loss
0.85 kW
1.20 kW
Required cooling air flow 83 l/s 83 l/s
Weight 26 kg 26 kg
Table 7- 11 PM240-2, IP20, FSF, 3 AC 200 V … 240 V
Article No. - without filter
6SL3210-…
…1PC31-3UL0
…1PC31-6UL0
…1PC31-8UL0
LO base load power
LO base load input current
LO base load output current
37 kW
126 A
130 A
45 kW
149 A
154 A
55 kW
172 A
178 A
HO base load power
HO base load input current
HO base load output current
30 kW
110 A
104 A
37 kW
138 A
130 A
45 kW
164 A
154 A
Siemens fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3 NE1 225-0 / 200A
175 A
3 NE1 225 -0 / 200A
200 A
3 NE1 227-0 / 250A
225 A
Power loss
1.44 kW
1.79 kW
2.18 kW
Required cooling air flow
153 l/s
153 l/s
153 l/s
Weight
57 kg
57 kg
57 kg
