Setting up and connecting the device
3.3 Connecting the device
MD-34A
38 Operating Instructions, 08/2023, A5E52427535-AA
What to keep in mind during mains operation
Risk of fire and electric shock
The On/Off button does not completely isolate the device from the power supply. If the
device is switched off with the On/Off button, there is still a risk of electric shock and fire,
for example, if the device or the connection cables are damaged, or in the event of
improper use.
When working on the device or if the device is not used for a long period of time, always
disconnect it fully from the power supply. Shut down the operating system and if you are
using the device in mains operation, pull out the power plug.
Localized information
For the United States and Canada
For the United States and Canada, a CSA or UL-listed power cord must be used.
The connector must be compliant with NEMA 1-15P (NEMA; National Electrical Manufacturers
Association).
• 120 V/240 V supply voltage
A flexible cable with UL approval and CSA marking must be used. In addition, the cable
must exhibit the following properties:
– SPT-2 or SVT with three wires
– At least 18 AWG conductor cross-section (AWG: American Wire Gauge, US standard for
cable diameter)
– Max. length of 4.5 m
– Connector 15 A, min. 125 V
For countries other than the USA and Canada
• 230 V supply voltage
This device is equipped with a safety-tested power cord. If you choose not to use this
cable, you must use a flexible cable of the following type: At least 18 AWG (0.82 mm
2
)
conductor cross-section and 15 A/250 V connector. The cable set must conform to the
safety regulations of the country in which the devices are installed, and bear the
prescribed markings in each case.
