Operating the device
5.1 Operator input options
SIMATIC IPC377E
42 Operating Instructions, 2017/05, A5E40965249-AA
5.1
Operator input options
Depending the connected I/O devices, the following operator input options are available:
Touch screen
CAUTION
Unintentional actions with touch screen operation
If you touch the touch screen while system-internal processes are running, unintended
reactions of the device may be triggered.
Do not touch the screen in the following situations:
During the boot process
When plugging or unplugging USB components
While Scandisk is running
During a BIOS update
NOTICE
Damage to the touch screen
Hitting the touch screen with hard objects may damage it and can result in a total failure
of the touch screen.
Only touch the touch screen with your fingers or a suitable touch stylus.
Screen keyboard for touch device
External keyboard, connected via USB
External mouse, connected via USB
5.2
IPC calibration function
Software introduction
After install the Touch driver in Installing the drivers on Windows 7 (Page 64), you will see
the HIDeGalax Touch software is installed in IPC automatically.
The HIDeGalax Touch software contains the following features:
Advanced touch features
Calibrating
This calibration function has three calibration methods: 4 points calibration, 9 points
calibration and 25 points calibration. You can select any of them for calibrating as your
request.
