Technical specifications
8.5 Hardware description
SIMATIC IPC377E
82 Operating Instructions, 2017/05, A5E40965249-AA
Pin
Short description
Meaning
6
BI_DB–
Bidirectional data B–, input/output
7 BI_DD+ Bidirectional data D+, input/output
8
BI_DD–
Bidirectional data D–, input/output
LED
Short description
Meaning
1 LED 1 Off: Port is Not Active
Lit orange: Port is Active, but No Data Activity
Blinking: Port is Active and there is Data Activity
2 LED 2 Off: 10Mbps
Lit red: 100Mbps
Lit green: 1Gbps
8.5.3
Internal interface
8.5.3.1
Overview of internal interfaces
Interface
Position
Connect-
or
Description
Mini PCIe x1
Internal
PCIe x1 interface
mSATA x 1
internal
mSATA x 1 interface with USB2.0 signal
8.5.3.2
Mini PCIe and mSATA interface
Assignment of the PCIe x1 interface
Top side
Bottom side
Pin no.
Name
Description
Pin no.
Name
Description
1 WAKE# Signal for link
reactivation
2 3.3 V 3.3 V power
3
Reserved**
4
GND
Ground
5
Reserved**
6
1.5 V
1.5 V power
7
CLKREQ#
Clock request
8
UIM PMR
9
GND
Ground
10
UIM DATA
11 REFCLK- Reference clock
(differential
pair)
12 UIM CLK
13 REFCLK+ Reference clock
(differential
pair)
14 UIM RESET
15
GND
Ground
16
UIM VPP
