Installing and connecting the device
3.3 Connecting the device
SIMATIC IPC377E
34 Operating Instructions, 2017/05, A5E40965249-AA
Switch off the 24 VDC power su
pply.
Connect the wires of the power supply.
erminal at the
Connect device to networks
The following options are available for integrating the device in existing or planned system
environments and networks.
You can use the integrated Ethernet interfaces (10/100/1000 Mbps) for communication and
data exchange with automation devices, e.g. SIMATIC S7.
You need a suitable software to use this functionality: STEP 7, WinCC, WinAC,
SIMATIC NET.
