Siemens SIMATIC IPC377E User Manual

Technical specifications
8.6 BIOS description
SIMATIC IPC377E
84 Operating Instructions, 2017/05, A5E40965249-AA
8.6
BIOS description
8.6.1
BIOS getting started
BIOS setup utility: Aptio TSE
The motherboard's BIOS is developed on AMI based code. AMI provides Aptio
TM
Text Setup
Environment (TSE), a test-based basic input and output system as BIOS setup utility. The
purpose of Aptio
TM
TSE is to empower the user with complete system control at boot.
Getting BIOS setup
To enter BIOS Setup at startup:
1. Power on the motherboard.
2. Press
DELETE
or
ESC
key on your keyboard during the Power - On - Self - Test (POST)
when the SIEMENS logo is shown on screen.
The Aptio
TM
TSE main BIOS setup menu is displayed.
You can access the other setup screens from the main BIOS setup menu, such as
'Advanced' or 'Chipset' menus.
NOTICE
• If
DELETE
or
ESC
is not pressed, POST continues its routines.
• If the timing is missed for entering BIOS setup during POST, a system reset is required
by one of following methods:
– Press
CTRL
+
ALT
+
DELETE
simultaneously.
–
Press the power button to turn off system then turn it on.
BIOS setup menu
The Aptio
TM
TSE BIOS setup menu is the first screen that you can navigate. Each BIOS
setup menu option is described in this manual.
Navigation
The Aptio
TM
TSE keyboard-based navigation can be accomplished using a combination of
the keys, for example, function keys,
ENTER
,
ESC
,
ARROW
keys. Function description for
navigation keys is listed below.
Press
To
→ ← : Select Screen
Menu Bar and select a BIOS setup page, for example, the Main page.
↑ ↓/Click : Select Item
Select a BIOS setup item or sub page.
Enter/Dbl Click : Select
Select an option to edit its value or access a sub menu.
