Technical specifications
8.6 BIOS description
SIMATIC IPC377E
Operating Instructions, 2017/05, A5E40965249-AA
85
Change the field value of a particular setup item, for example, date, time.
F1 : General Help To display the general help window.
To enable user to load previous values in BIOS setup Menu.
F3: Optimized Defaults To enable user to load optimized default values in BIOS Setup Menu.
To enable user to save the current configuration and exit BIOS Setup Menu.
ESC/Right Click: Exit
The <ESC> Key or Right Click allows user to discard any change have made and exit BIOS
Setup Menu.
Press <ESC> Key or Right Click to exit BIOS Setup Menu without saving change. The
following screen will appear:
You can press <Enter> Key to discard changes and exit. Or use arrow keys to select “No”
then press <Enter> Key to abort this function and return to previous screen.
Main setup
The main setup menu
The main setup menu is shown as below.
Note
Take the BIOS version installed on your IPC as standard.
