Technical specifications
8.6 BIOS description
SIMATIC IPC377E
94 Operating Instructions, 2017/05, A5E40965249-AA
Select
from the BIOS setup page to enter the boot setup page. The boot page is shown
as below.
In the Boot configuration page, you can modify the boot up screen between POST message
and SIEMENS logo.
Follow the instructions below to select your boot-up screen.
1. Select
with the arrow keys and press
key.
2. Select the
or
as you want and press
key.
3. Press
key and save the change.
See the quiet boot options below:
Set the motherboard to display the POST message.
Enabled Set the motherboard to display the SIEMENS logo. This is the default set-
Note
If quiet boot function is set as Enabled
in BIOS, you can press TAB key to switch to POST
the IPC is booting.
