Technical specifications
8.4 Technical data
SIMATIC IPC377E
Operating Instructions, 2017/05, A5E40965249-AA
77
8.4.4
Power supply 12" device
Maximum permitted current consumption at the USB ports
Auxiliary components
Maximum permitted power consumption
Max. total power
+5 V
+3.3 V
+1.5 V
USB device
3.0
High
current
900 mA - - 6 W (for all USB
devices)
Low cur-
rent
100 mA - -
USB De-
vice 2.0
High
current
500 mA - -
Mini PCIe
module
Per slot - 1.5 A
1
0.5 A
2
1 W in total
mSATA
module
Per slot - 1.5 A
1
0.5 A
2
1
May amount to maximum 3.0 A for up to 100 ms at start-stop torque of device.
2
May amount to maximum 1.2 A for up to 100 ms at start-stop torque of device
DC power supply
Input voltage
24 VDC (20.4 to 28.8 VDC)
Power consumption
1
Max. 30 W
Power failure buffering Hold-up time > 10 ms
(DC_FAIL becomes active after > 5 ms)
1
The performance specifications apply to the power supply component, but not to the device.
Note
Inrush current
The device needs
an inrush current of at least 4 A for 25 ms.
The peak value of the inrush current depends on the input voltage and the impedance of the
24 V source; peak currents in excess of 4 A are possible. This will not have a negative
impact on device functionality.
