Technical specifications
8.4 Technical data
SIMATIC IPC377E
76 Operating Instructions, 2017/05, A5E40965249-AA
Operation
1080 to 795 hPa,
corresponds to an elevation of -1000 to
Storage/transport 1080 to 660 hPa,corresponds to an eleva-
Mechanical ambient conditions
Vibration, tested in accordance with DIN IEC 60068-2-6
Operation
With hard disk :
• 10 to 58 Hz: 0.0375 mm
• 58 to 200 Hz: 4.9 m/s²
Storage/transport
• 5 to 8.4 Hz: 3.5 mm
• 8.4 to 500 Hz: 9.8 m/s2
Shock resistance, tested in accordance with IEC 60068-2-27, IEC 60068-2-29
Operation
• With hard disk: 9.8 m/s
2
, 20 ms;
Storage/transport
• 250 m/s2, 6 ms
Shipbuilding
Ambient conditions for use of the devices in shipbuilding
The device is suitable for shipping and offshore applications. The installation and attachment
conditions are the same as those for industrial applications.
See the shipbuilding approvals of the individual shipbuilding companies in the section
"Certificates and approvals" to learn about the required ambient conditions.
Ambient conditions and installation guidelines
The permissible ambient conditions and installation guidelines can be found in the
certificates of the individual shipbuilding companies.
