Siemens SIMATIC IPC377E User Manual

Technical specifications
8.5 Hardware description
SIMATIC IPC377E
80 Operating Instructions, 2017/05, A5E40965249-AA
Pin
Short description
Meaning
6
nc
7 nc
8
nc
9 nc
8.5.2.4
USB 2.0 port
Pin
Short description
Meaning
1
USB_P5V_fused (O)
+5 V, fused
2
USB_D0M (I/O)
Data–
3
USB_D0P (I/O)
Data+
4
USB_GND
GND
8.5.2.5
USB 3.0 port
Pin
Short name
Meaning
Input / output
1 VBUS + 5 V (fused) Output
2
D-
Data channel USB2
Input / output
3 D+ Data channel USB2 Input / output
4
GND
Ground
–
5
RX-
Data channel USB3
Input
6
RX+
Data channel USB3
Input
7
GND
Ground
–
8
TX-
Data channel USB3
Output
9
TX+
Data channel USB3
Output
