Technical specifications
8.5 Hardware description
SIMATIC IPC377E
78 Operating Instructions, 2017/05, A5E40965249-AA
8.5
Hardware description
8.5.1
Technical features of the motherboard
Component /
port
Description
Parameters
Chipset
integrated in CPU
CPU Intel Celeron N3160
Memory
DDR3L SODIMM
2 GB, 4 GB and 8 GB
Graphics Integrated graphics up to 512 MB graphics memory taken
dynamically from RAM
8.5.2
External interfaces
8.5.2.1
Overview of interfaces
Interface
Position
Description
COM External 9-pin D-sub:
• 2 x RS 232
• 2 x RS 232/ RS 422/ RS 485
USB
1
External 2 × USB 3.0
2 × USB 2.0
Ethernet External 2 x RJ45
10/100/1000 Mbps
DisplayPort External 1 x DPP
1 x VGA
1
Only two of these USB ports may be operated simultaneously in high current mode, max. 6 W.
8.5.2.2
DC in connector
Pin
Short description
1
24V
2
GND
