Process interfacing via an automation system (PLC, PC)
9.4 Control with FB 79
SIMATIC MV500
Operating Instructions, 06/2018, C79000-G8976-C494-01
135
Note
Reaction when an error occurs
After an error has occurred, you will need to set the "SEL0" to "SEL3" signals and the "TRN"
signal to "0" and then reset the error with the "RES" signal. The "DISA" signal must have the
value "1" (no edge change).
Table 9- 40 Sequence when saving the program
Step
Input
Output
Description
1 DISA = 1
Apply for at least 100 ms:
SEL0 = 1
SEL1 = 1
SEL2 = 0
SEL3 = 1
Disable keyboard control. DISA must have the
value 1. No edge change is necessary.
Select program to be saved, for example
code 11.
2 TRN = 1
SEL0, SEL1, SEL2,
SEL3 = 0
Start program saving
TRD = 0
RDY = 0
TRD signal changes to FALSE
RDY signal changes to FALSE
3 Wait at least 200 ms
SEL1 = 1
Feed in object with data matrix code.
Save program
Apply for at least 5 ms:
TRG = 1
Trigger signal
4
TRD = 1
Selected program has been saved.
SEL1=0
Reset signals.
5 TRN = 0 Exit program saving.
TRD = 0
TRD signal changes to FALSE for 150 ms.
TRD = 1
TRD signal changes to TRUE.
RDY = 1
Program saving is exited.
