Process interfacing via an automation system (PLC, PC)
9.4 Control with FB 79
SIMATIC MV500
144 Operating Instructions, 06/2018, C79000-G8976-C494-01
Table 9- 45 Possible values of the "COMMAND" parameter
Value (W#16#...)
Meaning
0000
Cancel current job or no job
0001 Change program
0002
Save program
0003 Output the number of the program currently selected on the optical reader
0004
Output the current operating state of the optical reader
0005
Reset DISA control signal
0081
Output the (possibly modified) result string
0082
Output absolute quality characteristics
0083
Output absolute quality characteristics and output result string
0084
Output quality characteristics as classes
0085
Output quality characteristics as classes and output result string
0086
Output quality characteristics as classes and in absolute format
0087 Output quality characteristics as classes and in absolute format and output result
string
0088
Output code position
0089
Output code position and result string
008A
Output code position and absolute quality characteristics
008B
Output code position and absolute quality characteristics and output result string
008C
Output code position and quality characteristics as classes
008D
Output code position and quality characteristics as classes and output result string
008E
Output code position and quality characteristics as classes and in absolute format
008F Output code position and quality characteristics as classes and in absolute format
and output result string
Note
Requirements
To edit this job, the following parameters must be set in the "Settings > Communication >
Use > Connections" menu in the WBM:
•
Text: PROFINET IO
Output of the result string (except commands 4 and 5)
•
Controller: PROFINET IO
Interface for the "DISA", "SEL0 ... SEL3", "TRN", "RES", "IN_OP", "TRD", "RDY" signals
