Service and maintenance
10.1 Error and diagnostics messages
SIMATIC MV500
Operating Instructions, 06/2018, C79000-G8976-C494-01
177
Error
message
Value
Onboard
PROFINET
Value
TCP/IP and
RS232
Value
Ident
profile,
STATUS
byte
Description
Corrective measures
Error
Transfer error
archiving/
MMI
W#16#5007 07 E1FE04 The send buffer is full
because the data cannot
be sent in an adequately
short time or the server is
not confirming receipt of
the data in time.
Reduce the trigger frequency or
reduce the amount of diagnostic
data to be archived. Process the
results on the server side faster.
A high load on the network to
which the optical reader is con-
nected can also block the trans-
fer of the data. If necessary,
check the network connection.
Error
Transfer error
PROFINET I
O
W#16#5007 07 E1FE04 The send buffer is full
because the data cannot
be queried in an ade-
quately short time.
Reduce the trigger frequency or
process the results faster. If
necessary, change the update
time in the PROFINET configura-
tion.
Error
Transfer error
CM/PROFIN
ET IO
W#16#5007 07 E1FE04 The send buffer is full
because the data cannot
be queried in an ade-
quately short time.
Reduce the trigger frequency or
process the results more quickly
on the CPU. The transmission
speed of the communication
module connection can possibly
be increased.
To cover short-term peak loads,
the size of the image buffer in the
WBM can be increased un-
der"Program > Image acquisition
> Mode".
Error
Program
requires EF
lens
W#16#5011 17 E1FE06 An EF lens is configured
in the program but it is not
connected.
Reconnect the EF lens or change
the parameter assignment of the
program.
Error
Save pro-
gram
W#16#500A 10 E6FE04 The program could not be
created.
Adapt the parameter assignment,
the placement of test objects in
the image or the image quality.
Error
Match error
W#16#500B 11 E1FE07 The program could not be
created due to faulty
match settings.
Adapt the match settings or use
a suitable test object.
Error
Timeout
during saving
W#16#500D 13 E6FE04 The "Save program" pro-
cess was canceled be-
cause it took too long.
Check the program settings and
start the "Save program" process
via the WBM, if necessary.
Error
TCP commu-
nication
W#16#500E 14 E1FE01 Connection error in com-
munication over a TCP
connection or when using
an Ethernet RS-232 con-
verter: There is no TCP
connection or the data
transfer cannot be com-
pleted within the set time
limit.
Make sure that the connected
TCP partner is correctly config-
ured and ready to receive.
