Service and maintenance
10.1 Error and diagnostics messages
SIMATIC MV500
178 Operating Instructions, 06/2018, C79000-G8976-C494-01
Error
message
Value
Onboard
PROFINET
Value
TCP/IP and
RS232
Value
Ident
profile,
STATUS
byte
Description
Corrective measures
Error
Archiving/
MMI commu-
nication
W#16#500E 14 E1FE01 Error in communication
over the archiving connec-
tion: There is no TCP
connection, the server
does not respond within
the set time limit or vio-
lates the archiving proto-
col.
Check the connection to the
server. Make sure that the data is
processed by the server in an
adequately short time and that
the protocol is maintained.
Error
Lamp over-
load
W#16#500F 15 E4FE06
The connected lamp was
overloaded. The config-
ured or specified "Maxi-
mum duty cycle" under
"Settings > Options >
Lighting" has been ex-
ceeded.
Decrease the trigger frequency,
reduce the exposure time or use
a more powerful lamp.
Error
invalid pro-
gram number
W#16#5010 16 E6FE04 An attempt is being made
to save a program under
an invalid number via the
interface set in "Control-
ler".
Select a program number be-
tween 1 and 15.
Error
PROFINET
IO connec-
tion error
W#16#5012 18 -- PROFINET IO connection
termination
The connection to the
PROFINET IO controller was
interrupted. Check the connec-
tion to the I/O controller.
Error
PROFINET
IO controller
status
"STOP"
-- 21 -- PROFINET IO controller
is in "STOP" status
Note:
No diagnostic interrupt is
sent to the I/O controller
The PROFINET controller is in
"STOP" mode, which means it
cannot receive commands from
the optical reader. Make sure
that the I/O controller changes
back to "RUN" status.
Error
PROFINET
I/O configura-
tion error
W#16#5016 22 -- Faulty PROFINET IO
configuration
The PROFINET IO configuration
of the optical reader and that of
the communication partner do
not match. Check the PROFINET
mode in the optical reader and in
the I/O controller.
Error
PROFINET
IO compatibi-
lity error
W#16#5017 23 -- Version incompatibility of
the PROFINET IO control-
ler to the I/O device (opti-
cal reader)
The version of the I/O controller
is out of date and not compatible
with the current version of the
optical reader.
To correct this error, we recom-
mend that you upgrade the I/O
controller.
