Technical data
11.1 Technical specifications of SIMATIC MV540
SIMATIC MV500
196 Operating Instructions, 06/2018, C79000-G8976-C494-01
6GF3540-0CD10
6GF3540-0GE10
6GF3560-0HE10
Optical data
Design of image sensor/camera
• SIMATIC MV540 S:
CMOS 0.5 Megapixel; 800 × 600
• SIMATIC MV540 H:
CMOS 1.3 Megapixel; 1280 × 1024
• SIMATIC MV560 X:
CMOS 5.3 Megapixel; 2592 × 2048
Type of image capture Global shutter with manual or automatic exposure
time
Range
70 ... 3000 mm
1)
Mounting type of lens
C-mount lens connection
Type of light source
Built-in ring lights or external ring lights
Image acquisition frequency (max.)
• SIMATIC MV540 S: 120 Hz
• SIMATIC MV540 H: 100 Hz
• SIMATIC MV560 X: 35 Hz
Type of focusing
• Mini-lens: Manual adjustment on the lens
• EF lens: Automatic setting via WBM
Supply voltage, current consumption, power loss
Supply voltage
24 V DC (20.4 to 28.8 V DC)
Current consumption (at 24 V DC)
• Typical • 0.2 A
• 0.4 A with ring light (continuous light)
• Maximum • 2.0 A
Mechanical specifications
Housing
• Material • Die-cast aluminum (silicone-free)
• Color • TI-Grey
