Siemens SIMATIC MV540 H - Page 197

Technical data
11.1 Technical specifications of SIMATIC MV540
SIMATIC MV500
Operating Instructions, 06/2018, C79000-G8976-C494-01
197
6GF3540-0CD10
6GF3540-0GE10
6GF3560-0HE10
Permitted ambient conditions
Ambient temperature
• During operation • 0 … +50 °C
• During transportation and storage • -30 … +70 °C
Relative humidity (max.)
95%
Degree of protection
IP67 according to IEC 60529
Shock resistance
IEC 60068-2
Shock acceleration
300 m/s²
Vibration acceleration
40 m/s²
Design, dimensions and weight
Dimensions (W × H × D)
68 × 122 × 45 mm
Weight
0.55 kg
Type of mounting
4 x M4 screws
LED display design
7 LEDs
Standards, specifications, approvals
Approvals
CE
MTBF
61 years
1)
Using C-mount lenses and lens accessories, the range can be exactly matched to the application.
