Blocks and Their Functions S5-95F
9.3 Parameterizing Internal Functions in DB1
The S5-95F offers functions that you must program according to your requirements. These
functions are:
• Using interrupt inputs
• Using counter inputs
• Using the integral real-time clock
• Using failsafe onboard inputs and outputs
• Using failsafe external modules
• Exchanging data via SINEC L1
• Changing call-up interval for time-controlled program processing (OB13) (see Chapter 7)
• Assigning system parameters
Note
For systems requiring approval, you must use the COM 95F software package to
parameterize DB1 (see COM 95F manual).
On the following pages, the configuration of DB1 and the meaning of the default parameters are
described.
9-24 EWA 4NEB 812 6210-02
