Expansion of Basic System with External I/Os S5-95F
5.5 Connection of Failsafe I/O Modules
If the failsafe onboard inputs and outputs are not sufficient for your application, you can expand the
S5-95F with the following I/O modules:
Failsafe input module DI 431-8FA..
Failsafe output module DQ 450-8FA..
Please note that the reaction times change when you use I/O modules.
You can use the I/O modules DI 431-8FA.. and DQ 450-8FA.. both in single-channel and two-
channel operation. For safety functions, you must always use the modules in two-channel operation
and parameterize them with COM 95F.
No matter whether you operate the above-mentioned modules in single or two-channel operation,
the modules are subject to a high-grade function test.
Note
Make sure that the load voltage for all failsafe external I/O modules is connected. If the
load voltage is not connected, the S5-95F reacts with a fault message and with the
safety reaction programmed in DB1.
System Reaction to I/O Faults
The reaction to an I/O fault depends on whether you use the I/O modules in single or two-channel
operation.
When you use the I/O modules in
two-channel
operation, the S5-95F reacts as follows:
The yellow fault LED is set
The fault is entered into the system event DB 254
Error OB 37 is processed
System reaction as programmed in DB1
When you use the I/O modules in
single-channel
operation, the S5-95F reacts as follows:
The yellow fault LED is set
The fault is entered into the system event DB 254
Error OB 37 is processed
The user program is executed (no further system reaction)
