S5-95F Failsafe Mini PLC S5-95F
The Major Characteristics of the S5-95F and S5-115F at a Glance
Table 1-3. The Major Characteristics of the S5-95F and S5-115F at a Glance
Characteristics S5-95F S5-115F
Hardware
Subunit dimensions (W×H×D) in mm 145×135×146 482×302×210
Supply voltage 24 V DC 24 V DC
Digital inputs
- Failsafe onboard DIs
- Failsafe external DIs
- Non-failsafe external DIs
16
max. 128
max. 320
-
max. 1024
max. 1024
Digital outputs
- Failsafe onboard DQs
- Failsafe external DQs
- Non-failsafe onboard DQs
- Non-failsafe external DQs
8
max. 64
2×4
max. 320
-
max. 1008
-
max. 1008
Analog inputs
- Failsafe external AIs
- Non-failsafe external AIs
-
max. 32
max. 64
max. 64
Analog outputs
- Non-failsafe external AQs max. 16 max. 64
Failsafe, onboard counter inputs 2 -
Interrupt inputs
- Failsafe onboard interrupt DIs (OB2)
- Failsafe onboard interrupt DIs (OB3)
- Failsafe external interrupt DIs (OB2)
max. 4
max. 20
-
-
-
8
Interfaces PG/OP/TD/SINEC L1 PG/OP/SINEC L1
Failsafe point-to-point link no yes
Software
User memory
(1 statement corresponds to 2 bytes)
16 KB,
8 KB of which typ.
for program
37 KB
Run time of operating system approx. 50 ms approx. 80 ms
Execution time for 1024 binary statements 2 ms 2 ms
Number of flags
- Retentive
2048
512
2032
-
Number of counters
- Retentive
128
8
128
-
Number of timers 128 128
Program organization
- Structured programming
- Process interrupt handling
- Time-controlled program processing
- PID controller (non-failsafe)
yes
yes
yes
yes
yes
yes
yes
yes
a
a
a
a
