Operations List S5-95F
C 1.3 System Operations
Oper-
ation
(STL)
Permissible
Operands
1 RLO depend.
2 RLO affected
3 RLO reloaded
123
Typical
Execution Time
in µs
On- Ext.
board I/O
Function
SU RS N N Y 5.6 Set bit in system data area unconditionally.
RU RS N N Y 5.6 Reset bit in system data area unconditionally.
LIR N N N 170 Load the contents of a memory word (addressed by
ACCU 1) indirectly into the register (0: ACCU 1; 2:
ACCU 2).
TIR N N N 106 Transfer the register contents (0: ACCU 1; 2: ACCU 2)
indirectly into the memory word (addressed by ACCU 1).
TNB Parameter
n=0 to 255
N N N 1.2 ms+n·13 µs
Transfer a field byte by byte (number of bytes 0 to 255).
T RS N N N 17 Transfer a word to the system data area.
JU OB N N Y 110 Call an organization block unconditionally.
JC OB Y Y
1)
Y 110 Call an organization block conditionally.
ADD BN N N N 15 Add byte constant (fixed point) to ACCU 1.
ADD KF N N N 12 Add fixed-point constant (word) to ACCU 1.
STS N N N 2.4 Stop operation. Program processing is interrupted imme-
diately after this operation.
TAK N N N 12 Swap the contents of ACCU 1 and ACCU 2.
Set Operations
Load and Transfer Operations
Block Call Operations and Return Operations
Arithmetic Operations
Other Operations
C.1.4 Evaluation of CC 1 and CC 0
CC
1
CC
0
Arithmetic
Operations
Digital
Logic Operations
Comparison
Operations
Shift
Operations
Conversion
Operations
0 0 Result=0 Result=0 ACCU 2=ACCU 1 shifted bit=0 -
0 1 Result<0 - ACCU 2<ACCU 1 - Result<0
1 0 Result>0 Result 0 ACCU 2>ACCU 1 shifted bit=1 Result>0
C-12 EWA 4NEB 812 6210-02
