Siemens SIMATIC S5-95F User Manual

Module Spectrum S5-95F
A.2 Programmable Controller
Technical Specifications S5-95F (6ES5 095-8FA02)
Dimensions and Weight
Dimensions WxHxD (in mm) 145×135×146
(in in.) 5.7 × 5.3 × 5.7
Weight - S5-95F approx. 1.5 kg (3.3 lbs.)
Weight - memory submodule approx. 0.1 kg (3.5 oz.)
Internal Technical Specifications
Memory capacity
- internal RAM 16 KB, 8 KB for
control program
- EPROM submodule
Clock
- accuracy t
g
±1 s/day at 25 °C
(77 °F)
- variation due to temp. change t
A
0 to 60 °C
(32 to 140 °F)
Execution time
- per binary operation approx. 2 µs
Cycle monitoring time
- defined via hardware approx. 680 ms
- programmable via software 10 to 2550 ms
Flags 2048, (512 retentive)
Timers number/range 128; 0.01 to 9990 s
Counters number/range 128; 0 to 999 (8 retentive)
Inputs/outputs (onboard)
Digital inputs, failsafe 16
Digital outputs
- failsafe 8
- single-channel 2×4
Interrupt inputs, failsafe 4
Counter inputs, failsafe 2
External I/O modules
Digital modules max. 32
Analog modules max. 8
Permissible blocks
Organization blocks 1, 2, 3, 13, 21, 22,
31, 34, 37, 251
Program blocks 0 to 255
Function blocks 0 to 255
- integrated 240 to 243, 250 to
252, and 255
Sequence blocks 0 to 255
Data blocks 1 to 255
- reserved 1, 252 to 255
Operation set approx. 140
Output current
- from V 1 1 A
- from V 1 0.65 A
Short-circuit protection electronic
Class of protection Class I
Floating no
Back-up battery Lithium battery
(3.4 V/850 mAh)
- life expectancy min. 1 year
- service life (at 25 °C/77° F) approx. 5 years
Power loss of the module typ. 12 W
Power Supply (Internal)
Input voltage
- rated value 24 V DC
- permissible range 20 to 30 V
Current consumption from 24 V
- for the subunit typ. 160 mA
- for full external I/O
configuration typ. 1 A
Output voltage
- V 1 (for external I/O) +9 V
- V 2 (for programmer) +5.2 V
Specific Onboard I/O Specifications
For digital inputs:
Floating yes
- isolated in groups of 16
Input voltage
- rated value 24 V
- at "0" signal - 30 V to +5 V DC
- at "1" signal +13 V to +30 V DC
Input current
- at "0" signal <1.5 mA (Input
residual current,
2-wire BERO)
- at "1" signal <6.5 mA (at 30 V)
Delay time
- from "0" to "1" typ. 2.5 ms
- from "1" to "0" typ. 2.0 ms
Cable length unshielded max. 200 m (660 ft.)
For digital outputs:
Floating yes
- isolated in groups of 16
Load voltage L+
- rated value 24 V DC
- permissible range 20 to 30 V DC
(including ripple)
Output current for "1" signal
- failsafe outputs max. 0.75 A
- single-channel outputs max. 0.5 A
Lamp load max. 10 W
Residual current for "0" signal 50 µA
Output voltage
- for "0" signal max. 0.5 V (at 6 k load
resistance)
- for "1" signal max. L+- 0.5 V
(at
0.75 A/0.5A and
24 V DC)
Short-circuit protection electronic and
(not overload-resistant) thermal
Limitation of the voltage in-
duced on circuit interruption
- for failsafe outputs to - 11 V
- for single-channel outputs to - 16 V
Switching frequency
- resistive load max. 100 Hz
- inductive load max. 2 Hz
A-2 EWA 4NEB 812 6210-02
