S5-95F
Expansion of Basic System with External
/10s
5
Expansion of Basic System with External
1/0s
You can expand the programmable controllers by using S5-1OOU external
1/0
modules. If you install
S5-1 OOU external
1/0
modules, mount the controller, bus units, and interface module on a 35-mm
standard mounting rail and connect them to each other via the ribbon cables of the bus units. Each
bus unit has room available for two
1/0
modules.
Figure 5-1 shows a basic unit expanded with external
1/0s.
Figure 5-1.
Installation of a Basic Unit with External
1/0s
5.1
Assembling a Tier
To
expand a basic system with external
1/0
modules, you need the following parts for each subunit:
. An
S5-95F
basic unit
. Bus units (max. 8)
.
1/0
modules
. Standard mounting rail
Mount the first module on the far left end of the standard mounting rail and then add the other
modules to the right of the first module.
—
EWA 4NEB 8126210-02
5-1
