Dimension Drawings S5-95F
B.3 Interface Modules
Figure B-4. Dimension Drawing of the IM 315 Interface Module
135
(5.3)
135
(5.3)
45.4
(1.8)
35 (1.4)
26 (1)
min. 210 (8.3)
max. 570 (22.4)
13.5
(0.5)
81 (3.2)
B-4
EWA 4NEB 812 6210-02
