15.7 Evaluating Cycle Time Statistics
The S5-95F collects statistical data on cycle times. This statistical data is located in internal RAM in
the address space extending from 8004
H
to 80C3
H
. You can evaluate the cycle time statistic by
invoking the programmer function OUTPUT ADDRESS.
Functionality
The S5-95F computes the time needed for each cycle and assigns it to an interval. A counter is
then assigned to each interval. The S5-95F increments a counter by one whenever the cycle time
being measured belongs to that counter's interval.
The statistics function is located in internal RAM and comprises
• 95 counters of 2 bytes each (see Table 15-4) and
• a control byte
Table 15-4. Memory Allocation for the Cycle Time Statistics
