S5-95F Module Spectrum
* without connection of a programmer, operator panel, text display or SINEC L1
For digital outputs (continued):
Total current
- for failsafe outputs 3 A
- for single-channel outputs 2 A
Driving of digital input possible
Parallel switching of outputs
- for failsafe outputs possible, if outputs
decoupled by a
diode
- for single-channel outputs 0.5 A each
Cable length, unshielded max. 200 m (660 ft.)
Current consumption from 24 V
- for failsafe outputs 50 mA
(all outputs "0")
- for single-channel outputs 20 mA
(all outputs "0")
for interrupt inputs
Floating yes
Input voltages and currents
as for digital inputs
(see Specific Onboard I/O Specifications)
Delay time
- from "0" to "1" typ. 1 ms
- from "1" to "0" typ. 1 ms
Pulse duration
* 2 ms
Cable length (shielded) 100 m (330 ft.)
Counter inputs
Floating yes
Input voltages and currents
as for digital inputs
(see Specific Onboard I/O Specifications)
Delay time
- from "0" to "1" typ. 1 ms
- from "1" to "0" typ. 1 ms
Counter frequency
* counter A: 350 Hz
counter B: 350 Hz
Pulse duration 1.4 ms
Cable length (shielded) 100 m (330 ft.)
