Design,
2.2
Functions and Operation
S5-95F
Basic System Design - with External 1/0s
You can expand the basic system by using S5-1OOU modules (external 1/0s). These external 1/0s
consist of functional units that you can combine according to the task you want to perform.
Example of a Subunit with External
1/0s
Figure 2-2.
Basic Unit with External l/Os
Basic Unit
For an S5-95F you always require two basic units. These two basic units are the core of the
programmable controller and are connected via a fiber optic cable.
External 1/0s
If you require more than the available onboard 1/0s or if you need special functions, you can
expand your basic system with additional external
1/0s.
The S5-95F can be expanded via bus units with S5-1OOU standard and failsafe modules. A
maximum of 8 bus units can be connected to each basic unit.
Bus Units with Terminal Blocks
(crimp snap-in or SIGUT)
Bus units are used to connect the S5-1OOU modules to the basic unit. One bus unit
accommodate two
1/0 modules.
Standard Mounting Rail
The power supply module, the basic unit and the required bus units are mounted on
standard mounting rail.
can
the
2-2
EWA 4NEB 8126210-02
