Testing the User Program and Storing It on the Memory Submodule S5-95F
Operating the Programmer in Safety, Quasi-Safety and Test Mode
Table 14-7. Operating the Programmer in Safety, Quasi-Safety and Test Mode
Functions Invoked on
the Programmer
Abbr.
STOP RUN STOP RUN
Block input and output
Input block
DB, FB, OB, PB, SB
Parameter control DB
INPUT
Yes
Yes
Yes
Yes
No
Yes
No
No
Output block with editing
DB, FB, OB, PB, SB
Parameter-Bedien-DB
OUTPUT
Yes
Yes
Yes
Yes
No
Yes
No
No
Output block without editing
DB, FB, OB, PB, SB
OUTPUT
Yes Yes Yes Yes
Test
Signal status display with editing
FB, OB, PB, SB
STATUS
Yes Yes No No
Signal status display without editing
FB, OB, PB, SB
STATUS
Yes Yes Yes Yes
PLC functions
Start PLC START Yes No Yes No
Stop PLC STOP No Yes No Yes
Compress PLC memory COMP Yes Yes Yes No
Status Variable STAT VAR Yes Yes Yes Yes
Force Variable with editing FORCE
VAR
Yes Yes No No
Force Variable without editing FORCE
VAR
Yes Yes Yes Yes
PLC info
Output address with editing OUTP ADR Yes Yes No No
Output address without editing OUTP ADR Yes Yes Yes Yes
Memory configuration SPAUS Yes Yes Yes Yes
Read system parameters SYSPAR Yes Yes Yes Yes
Output block stack BSTACK Yes No Yes No
Output interrupt stack ISTACK Yes No Yes No
Auxiliary functions
Transfer block from PG PLC
DB, FB, OB, PB, SB
Parameter control DB
TRANS
Yes
Yes
Yes
Yes
No
Yes
No
No
Transfer block from PLC PG TRANS Yes Yes Yes Yes
Overall PLC reset RESET Yes No Yes No
Output directory DIR Yes Yes Yes Yes
Quasi-/
Safety Mode
Test
Mode
