Error Diagnosis and Elimination S5-95F
Table 15-2. Evaluating System Events in DB254 (continued)
Error No.
(Decimal)
Primary
Information
Auxiliary
Information
Corrective
Measures
69 Configuring error in DB1
parameter block for short-
circuit test
(Response: Soft STOP)
Check configuring data in
DB1
- Combining of interrupt
DI and non-interrupt DI
not allowed
70 Configuring error in DB1
(Error response: Soft STOP)
Byte 2:
Syntax error in DB1, data
word: (high address)
Byte 3:
Syntax error in data
word: (low address)
Check configuring data in
DB1
71 Error in standard FB
(Error response: Soft STOP)
Byte 2:
88
H
:
FB in RAM
C8
H
:
FB in EPROM
Byte 3:
Block No.
Reload standard FB
72 OB13 too long or specified
OB13 interval too short
(Error response: Soft STOP)
Optimize or shorten OB13
Increase OB13 call interval
in DB1
73 Battery discharged
Power-down in 72 h
(Response: Error message)
Replace battery
immediately
74 Battery failure exceeds 72 h
(Error response: Soft STOP)
Insert battery and execute
a cold restart
75 Load voltage for onboard I/Os
failed or not connected
(Error response: Soft STOP)
Check load voltage supply
76 Load voltage for counters
and/or hardware interrupts
failed
(Error response: Soft STOP)
Check load voltage supply
