S5-95F Application
PB1 STL Description
Preset values for flags used in FB255
0000 :L KF +15 Job no. 15: Short-circuit test
0002 :T FY 110
0003 :L KF +0 Relevant for job no. 2 only
0005 :T FW 112
0006 :L KM 00000000 00000011 Test outputs Q33.0 and Q 33.1
0008 :T FY 115
0009 :L KF +0 Flag byte for parameter assignment errors and
000B :T FY 116 for test results
000C :BE
