S5-95F Application
Configuring Inputs I32.0 and I32.1
In the case of a discrepancy on one of the redundant inputs I32.0/I32.1, the S5-95F is to passivate
all outputs allocated to signal group 5.
In addition, the S5-95F is to monitor inputs 32.0 and 32.1 for short circuits.
Set the cursor to the field for DI byte 32/column 0 (for bit 0).
Press RETURN <1>.
Result: The cursor is in the input field.
Enter a "5" in the "Signal group" input field.
Choose "Yes" by pressing <F3> in the "Short-circuit test DQ" input field; enter output Q33.0
as test bit.
Press RETURN <1>.
Result: The cursor is in the field for DI byte 32/column 1 (for bit 1).
Press RETURN <1>.
Result: The cursor is in the input field.
Confirm the "5" in the "Signal group" input field.
Choose "Yes" with <F3> in the "Short-circuit test" input field; enter Q33.1 as test bit.
Press ENTER <3>.
Result: COM 95F accepts all entries as made.
Configuring Output Byte 32
Output byte DQ 32 is to be assigned signal group 5.
Select the "Configuring the onboard DQ (DQ 32)" screen form.
Enter a "5" as "Signal group".
Exit the "Configuring the onboard DQ (DQ 32)" form by pressing ENTER <3>.
Result: COM 95F accepts all entries as made.
Terminate configuring of the onboard I/Os by pressing <F8>.
Result: COM 95F accepts all entries as made.
Configuring Signal Groups
If an error occurs in input byte 32 or output byte 32, the S5-95F passivates both bytes.
Signal group 5 is to be configured accordingly.
Select the "Configuring the signal groups" screen form by pressing function key <F3>.
Position the cursor to the field for signal group 5.
Press <F3> to select "P" for "Passivate".
Exit the "Configuring the signal groups" screen form by pressing ENTER <3>.
Result: COM 95F accepts all entries as made.
Terminating Parameter Input
Exit COM 95F by pressing <F8> three times in succession.
Result: COM 95F generates DB1 and transfers it to the specified program file.
EWA 4NEB 812 6210-02
17-9
