Application S5-95F
Note
The Reset button starts FB255, initiating depassivation. Depassivation takes about 30
seconds, after which the S5-95F is fully functional.
Before the S5-95F once again includes the defective component in the cycle, it is tested.
This test is particularly apparent when digital outputs are involved, as the LEDs on the
digital output modules light up briefly.
17-12
EWA 4NEB 812 6210-02
