3.3 Configure visualization
S7-1500
Getting Started, 05/2014, A5E03981761-AC
95
Configuring HMI connection
Introduction
You configure an HMI connection between the Comfort Panel TP1200 and the CPU via
PROFINET in the "Devices & Networks" editor.
The available communication partners in the project are displayed graphically in the network
view.
Communication via Ethernet
In Ethernet-based communication, the end user is responsible for the security of his data
network.
Targeted attacks can overload the device and interfere with proper functioning.
The following communication partners are created in the "Devices & Networks" editor:
● HMI device: SIMATIC Comfort Panel
● CPU: SIMATIC S7-1500
