Digital modules

3.25 Digital output module SM 322; DO 8 x DC 48-125 V/1.5 A; (6ES7322-1CF00-0AA0)

S7-300 Automation System Module data

3-82 Manual, 08/2006, A5E00105505-04

3.25 3.25 Digital output module SM 322; DO 8 x DC 48-125 V/1.5 A;

(6ES7322-1CF00-0AA0)

Order number: "Standard module"

6ES7322-1CF00-0AA0

Order number: "SIPLUS S7-300 module"

6AG1 322-1CF00-2AA0

Properties

Properties of SM 322; DO 8 x DC 48-125 V/1.5 A:

● 8 outputs, with reverse polarity protection, and electrically isolated in groups of 4

● Output current 1.5 A

● Rated load voltage 48 VDC to 125 VDC

● suitable for solenoid valves, DC contactors and signal lamps

● Group error display (SF)

Use of the module with high-speed counters

Please note when using the module in combination with high-speed counters:

Note

When using a mechanical contact to switch on the power supply, the outputs of SM 322; DO

8 x DC 48-125 V/1.5 A will carry a "1" signal for the duration of approx. 50 µs due to the

circuit structure.
