6.12 Analog output module SM 332; AO 4 x 16 bit; isochronous; (6ES7332-7ND02-0AB0)
S7-300 Automation System Module data
Manual, 08/2006, A5E00105505-04
6-107
6.12 6.12 Analog output module SM 332; AO 4 x 16 bit; isochronous;
(6ES7332-7ND02-0AB0)
Order number
6ES7332-7ND02-0AB0
Properties
● 4 outputs in 4 channel groups
● The output channels can be programmed as
– Voltage output
– Current output
● Resolution 16 bits
● Isochronous mode supported
● Supports the "CiR" function
● Programmable diagnostics and diagnostic interrupt
● electrical isolation between:
– backplane bus interface and analog output channel
– analog output channels
– analog output and L+, M
– Backplane bus circuit and L+, M
Diagnostics
For information on diagnostics message consolidated at the "group diagnostics" parameter,
refer to the table
Diagnostics messages of analog output modules .
Terminal assignment
The following diagrams show wiring examples.
Note
When you switch the rated load voltage (L+) off and on, the output may carry incorrect
interim values for the duration of for approx. 10 ms.
