Parameter sets of signal modules
A.11 Parameters of analog IO modules
S7-300 Automation System Module data
A-40 Manual, 08/2006, A5E00105505-04
Output type and output range
The table lists the output types/ranges of SM 332; AO 8 x 12 Bit, including their codes. Enter
these codes at bytes 2 to 9 in data record 1 (refer to the previous figure.)
Table A-31 Output range codes of analog output module SM 332; AO 8 x 12 Bit
Output type Code Output range Code
Disabled 2#0000 Disabled 2#0000
Voltage 2#0001 1 V to 5 V
0 V to 10 V
± 10 V
2#0111
2#1000
2#1001
Current 2#0010 0 mA to 20 mA
4 mA to 20 mA
± 20 mA
2#0010
2#0011
2#0100
A.11 A. 11 Parameters of analog IO modules
Parameters
The table below lists all parameters you can set for analog IO modules.
The comparison illustrates the editable parameters:
● in
STEP 7
● using SFC 55 "WR_PARM"
Parameters set in
STEP 7 can also be transferred to the module using SFC 56 and SFC 57
(refer to the
STEP 7 manuals).
Table A-32 Parameters of analog IO modules
Programmable, using ...
Parameters Data record number
... SFC 55 ... PG
Measuring method Yes Yes
Measuring range Yes Yes
Integration time Yes Yes
Output type Yes Yes
Output range
1
Yes Yes

Siemens SIMATIC S7-300 Module data Specifications

General

Series	S7-300
Manufacturer	Siemens
Protection Class	IP20
System	SIMATIC S7-300
Digital Inputs	Varies by module
Digital Outputs	Varies by module
Analog Inputs	Varies by module
Analog Outputs	Varies by module
Central Processing Unit	Varies by CPU model
Supply Voltage	24V DC or 120/230V AC
CPU Type	Varies (e.g., CPU 312, CPU 315, etc.)
Memory	Varies by CPU model
Communication Interfaces	MPI, PROFIBUS
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 70°C
Relative Humidity	10% to 95% (non-condensing)
