6.5 Analog input module SM 331; AI 8 x 14 Bit High Speed; synchronous; (6ES7331-7HF0x-0AB0)
S7-300 Automation System Module data
6-34 Manual, 08/2006, A5E00105505-04
6.5.2 Adjustable parameters
Introduction
For information on programming analog modules, refer to the chapter Programming analog
modules
.
Parameters
Table 6-15 Overview of parameters for SM 331; AI 8 x 14 Bit High Speed
Parameters Range of values Default Parameter
type
Scope
Enable
• Diagnostic interrupt
• Hardware interrupt when limit
exceeded
Yes/no
Yes/no
No
No
Dynamic Module
Fast Mode (can only be set if the
331-7HF01 was registered for
synchronous operation in the DP
slave properties)
Yes/no No static Module
Hardware interrupt trigger
• High limit
• Low limit
May be restricted by the measuring range.
from 32511 to - 32512
from - 32512 to 32511
- Dynamic Channel
Diagnostics
• Group diagnostics
Yes/no No static Channel
group
Measurement
• Measuring method
disabled
V voltage
4DMU current (4-wire transducer)
2DMU current (2-wire transducer)
V
• Measuring range
See table Measuring methods and ranges ± 10 V
• Noise suppression
none; 400 Hz; 60 Hz; 50 Hz 50 Hz
Dynamic
Channel or
channel
group
See also
Programming analog modules (Page 5-31)
