Other signal modules
7.2 Simulator module SM 374; IN/OUT 16; (6ES7374-2XH01-0AA0)
S7-300 Automation System Module data
7-2 Manual, 08/2006, A5E00105505-04
7.2 7.2 Simulator module SM 374; IN/OUT 16; (6ES7374-2XH01-0AA0)
Order number
6ES7374-2XH01-0AA0
Properties
Properties of simulator module SM 374; IN/OUT 16:
Simulation of:
16 inputs or
16 outputs or
8 inputs and 8 outputs (each with the same start addresses!)
Status displays for the simulation of inputs and outputs
Function adjustable with screwdriver
Note
Do not operate the function selection switch in RUN!
Configuration in
STEP 7
The simulator module SM 374; IN/OUT 16 is not included in the
STEP 7
module catalog.
STEP 7
therefore does not recognize the SM 374 order number. "Simulate" the simulator
module function required for your configuration as follows:
To use the SM 374 with 16 inputs, define the order number of a digital input module with
16 inputs in
STEP 7
,
for example: 6ES7321-1BH02-0AA0
To use the SM 374 with 16 outputs, define the order number of a digital output module
with 16 outputs in
STEP 7
,
for example: 6ES7322-1BH01-0AA0
To use the SM 374 with 8 inputs and 8 outputs, define the order number of a digital
input/output module with 8 inputs and 8 outputs in
STEP 7
,
for example: 6ES7323-1BH00-0AA0
