Siemens SIMATIC S7-300 Module data User Manual

Analog modules
6.4 Analog input module SM 331; AI 8 x 16 Bit; (6ES7331-7NF10-0AB0)
S7-300 Automation System Module data
Manual, 08/2006, A5E00105505-04
6-23
6.4.2 Adjustable parameters
Introduction
For information on programming analog modules, refer to the chapter Programming analog
modules
.
Parameters
Table 6-11 Overview of parameters of SM 331; AI 8 x 16 Bit
Parameters Range of values Defaults Parameter type Scope
Enable
• Hardware interrupt when limit
value is exceeded
• Hardware interrupt at end of cycle
• Diagnostic interrupt
yes/no
yes/no
Yes/no
no
no
no
dynamic
dynamic
dynamic
Module
Hardware interrupt trigger
• High limit
• Low limit
32511 to -32512
-32512 to 32511
-
-
Dynamic
Dynamic
Channel
Channel
Diagnostics
• Group diagnostics
• Wirebreak monitoring
Yes/no
Yes/no
No
No
static Channel
Channel
Measurement
• Module operating mode
• Noise suppression
• 8 channels
• 4 channels
50 Hz
60 Hz
400 Hz
50/60/400 Hz
Yes
No
50/60/400 Hz
Dynamic Module
Channel group
• Smoothing • None
• Low
• Average
• High
None Dynamic Channel group
• Measuring method • Measuring range
Dynamic Channel group
Disabled
Voltage
• ± 5 V
• 1 to 5 V
• ± 10 V
± 10 V
Current (4-wire transducer)
• 0 mA to 20 mA
• 4 mA to 20 mA
• ± 20 mA
4 mA to 20 mA
See also
Programming analog modules (Page 5-31)
Diagnostic messages of analog input modules (Page 5-33)
