Digital modules
3.34 Digital IO module SM 327; DI 8/DO 8 x DC 24 V/0.5 A; programmable (6ES7327-1BH00-0AB0)
S7-300 Automation System Module data
Manual, 08/2006, A5E00105505-04
3-123
Technical data
Actuator selection data
Output voltage
• with "1" signal
min. L+ (-1.5 V)
Output current
• with "1" signal
Rated value
Permissible range
0.5 A
5 mA to 0.6 A
• with "0" signal (residual current)
max. 0.5 mA
Output delay (resistive load)
• at "1" to "0"
• at "1" to "0"
max. 350 μs
max. 500 μs
Load resistance range 48 Ω to 4 kΩ
Lamp load max. 5 W
Wiring two outputs in parallel
• for redundant load control
supported
• for performance increase
not supported
Control of a digital input supported
Switching frequency
• with resistive load
• with inductive load to IEC 947-5-1, DC 13
• with lamp load
max. 100 Hz
max. 0.5 Hz
max. 10 Hz
Internal limiting of the inductive shutdown voltage to typ. L + (-54 V)
Short circuit-proof output Yes, electronic
• Threshold
typ. 1 A
Wiring the actuators With 20-pin front connector
