Siemens SIMATIC S7-300 Module data User Manual

General technical data
1.7 SIPLUS S7-300 Modules
S7-300 Automation System Module data
1-12 Manual, 08/2006, A5E00105505-04
SIPLUS S7-300 Modules
The table below lists all SIPLUS S7-300 modules.
In addition, we included the order numbers of the corresponding "standard" modules to
support project design. You can refer to specifications and technical data in the special
"standard" module section.
You will find more information about SIPLUS and contacts on the Internet at
http://www.automation.siemens.com/siplus
Table 1-2 SIPLUS S7-300 Modules
SIPLUS S7-300 modules for the use
under extended environmental
conditions
"Standard" modules
Module type
as of order no.
PS 305; 2A
PS 307; 5A
6AG1 305-1BA80-0AA0
6AG1 307-1EA80-0AA0
---
6ES7307-1EA00-0AA0
IM 153-1 6AG1 153-1AA03-2XB0 6ES7153-1AA03-0XB0
CPU 312C
CPU 313C
CPU 314
CPU 315–2 DP
6AG1 312-5BD00-2AB0
6AG1 313-5BE00-2AB0
6AG1 314-1AF10-2AB0
6AG1 315-2AG10-2AB0
6ES7312-5BD00-0AB0
6ES7313-5BE00-0AB0
6ES7314-1AF10-0AB0
6ES7315-2AG10-0AB0
IM 365 6AG1365-0BA01-2AA0 6ES7365-0BA01-0AA0
Digital input module
SM 321; DI 16 x DC 24V
SM 321; DI 32 x DC 24V
SM 321; DI 16 x DC 24V
SM 321; DI 16 x DC 24 V-125 V
SM 321; DI 8 x AC 120/230V
6AG1 321-1BH02-2AA0
6AG1 321-1BL00-2AA0
6AG1 321-7BH01-2AB0
6AG1 321-1CH20-2AA0
6AG1 321-1FF01-2AA0
6ES7321-1BH02-0AA0
6ES7321-1BL00-0AA0
6ES7321-7BH01-0AB0
6ES7321-1CH20-0AA0
6ES7321-1FF01-0AA0
Digital output module
SM 322; DO 16 x DC 24V/0.5A
SM 322; DO 8 x Rel. AC 230V/5A
SM 322, DO 8 x DC 48-125 V/1.5 A
SM 322; DO 8 x AC 120/230V/2A
SM 322; DO 8 x DC 24V/0.5A
6AG1 322-1BH01-2AA0
6AG1 322-1HF10-2AA0
6AG1 322-1CF00-2AA0
6AG1 322-1FF01-2AA0
6AG1 322-8BF00-2AB0
6ES7322-1BH01-0AA0
6ES7322-1HF10-0AA0
6ES7322-1CF00-0AA0
6ES7322-1FF01-0AA0
6ES7322-8BF00-0AB0
Digital I/O module
SM 323; DI8/DO8 x DC 24V/0.5A
6AG1 323-1BH01-2AA0 6ES7323-1BH01-0AA0
Analog input module
SM 331; AI 2 x 12Bit
6AG1 331-7KB02-2AB0 6ES7331-7KB02-0AB0
Analog output module
SM 332; AO 2 x 12Bit
6AG1 332-5HB01-2AB0 6ES7332-5HB01-0AB0
Analog IO module
SM 334; AI4/AO 2 x 12Bit
6AG1 334-0KE00-2AB0 6ES7334-0KE00-0AB0
