6.14 Analog output module SM 332; AO 2 x 12 Bit; (6ES7332-5HB01-0AB0)
S7-300 Automation System Module data
Manual, 08/2006, A5E00105505-04
6-127
Technical data
Status, interrupts, diagnostics
Interrupts
• Diagnostic interrupt
programmable
Diagnostics functions
• Group error display
• Reading diagnostics information
programmable
red LED (SF)
supported
Injection of substitution values Yes, programmable
Actuator selection data
Output ranges (rated values)
• Voltage
± 10 V
0 V to 10 V
1 V to 5 V
• Current
± 20 mA
0 mA to 20 mA
4 mA to 20 mA
Load impedance (in the rated range of the output)
• For voltage outputs
– capacitive load
min. 1 kΩ
max. 1 µF
• For current outputs
– at CMV < 1 V
– inductive load
max. 500 Ω
max. 600 Ω
max. 10 mH
Voltage output
• Short-circuit protection
• Short-circuit current
Yes
max. 25 mA
Current output
• Noload voltage
max. 18 V
Destruction limit against external voltages/currents
• Voltage at outputs to M
ANA
• Current
max. 18 V continuous;
75 V for the duration of max. 1 s (duty factor 1:20)
max. 50 mA d.c.
• Wiring the actuators
• For voltage output
– 2-wire connection
– 4-wire connection (measuring line)
• For current output
– 2-wire connection
with 20-pin front connector
supported
supported
supported
