Dimensional drawings
C.1 Dimensional drawings of the mounting rails
S7-300 Automation System Module data
C-6 Manual, 08/2006, A5E00105505-04
Mounting rail 2000 mm
The figure below shows the dimensional drawing of the 2000 mm mounting rail.



Figure C-9 Dimensional drawing of the 2000 mm mounting rail
Mounting rail for the "Insertion and Removal" function
The figure below shows the dimensional drawing of the mounting rail for the "Insertion and
Removal" function with active bus module, S7-300 module and explosion-proof partition. The
mounting rail has a length of 482.6 mm or 530 mm.






Explosion-proof partition
S7-300 module
active bus module
Mounting rail for the "Insertion and Removal" function
