Description of system components
8.5 Current / voltage measuring modules (UM, UM+) for the SIMOCODE pro V High Performance device series
SIMOCODE pro
System Manual, 05/2019, A5E40507475002A/RS-AD/004
141
See also Configuration information for SIMOCODE pro V when using an older basic unit
(Page 155) for more information.
Rated motor current is in the range from 2.4 - 2.99 A and a 1st generation current / voltage
measuring module with the 2.4 - 25 A measuring range is used
In this case, the 0.3 - 4 A measuring range must be used for the 2nd generation current /
voltage measuring modules.
This requires a change of the parameterization to the smaller measuring range (0.3 - 4 A).
Attention must be paid to this with regard to code conversion of the MLFB numbers.
The installation width of the two measuring ranges is identical.
