Mounting, wiring, connecting, system interfaces, configuration guidelines
12.2 Wiring, connecting
SIMOCODE pro
System Manual, 05/2019, A5E40507475002A/RS-AD/004
221
Decoupling module connection example
Figure 12-25 Decoupling module connection example
Wiring the removable terminals of the expansion modules and the decoupling module
Connect the equipment shield to the SPE terminal.
12.2.2 Wiring digital modules DM-F Local and DM-F PROFIsafe
Safety guidelines
See Manual Fail-safe Digital Modules SIMOCODE pro
(https://support.automation.siemens.com/WW/view/en/50564852
),
Chapter "Mounting and connection."
Loss of safety function is possible
For the 24 V DC power supply, always use an SELV or PELV power supply unit!
Note
Surge suppressors are required for inductive loads.
