Technical data
15.5 Technical data of the decoupling module
SIMOCODE pro
System Manual, 05/2019, A5E40507475002A/RS-AD/004
345
15.5 Technical data of the decoupling module
Technical data of the decoupling module
Mounting
Snap-mounted onto 35-mm standard mounting rail or
screw-mounted using additional push-in lugs.
Display
• Green "READY" LED
System interfaces
The left interface is for connection to a basic unit or an
expansion module, the right interface is exclusively for
connection to a current / voltage measuring module.
Connection cross sections
• Tightening torque
TORQUE: 7 LB.IN to 10.3 LB.IN 0.8 Nm to 1.2 Nm
• Connection cross sections
- Solid 2 x 0.5 mm
2
to 2.5 mm
2
/ 1 x 0.5 mm
2
to 4 mm
2
2 x AWG 20 to 14 / 1 x AWG 20 to 12
- Finely stranded with end sleeve 2 x 0.5 mm
2
to 1.5 mm
2
/ 1 x 0.5 mm
2
to 2.5 mm
2
2 x AWG 20 to 16 / 1 x AWG 20 to 14
