Siemens SIMOCODE pro V MR

Technical data
15.6 Technical data of the expansion modules
SIMOCODE pro
352 System Manual, 05/2019, A5E40507475002A/RS-AD/004
15.6.5 Safety-related technical data of the digital modules DM-F Local and DM-F
PROFIsafe
See "Technical Data" in the Manual "SIMOCODE pro Safety" fail-safe digital modules
(https://support.automation.siemens.com/WW/view/en/50564852
).
15.6.6 Technical data of the analog module
Technical data of the analog module
Mounting
Snap-mounted onto 35-mm standard mounting rail or screw-mounted
using additional push-in lugs
Display
• Green "READY" LED • Continuous light: "Ready for operation"
• Flashing: "No connection to basic unit"
System interfaces
For connecting to a basic unit, an additional expansion module, a current measuring
module or a current / voltage measuring module or the operator panel.
Control circuit
Connection type:
2-wire connection
Inputs:
• Channels
2 (passive)
• Parameterizable measuring
ranges
0/4 mA to 20 mA
• Cable shielding
Recommended for up to 30 m and outside the cabinet; shielding mandatory for cables
of 30 m or longer
• Max. input current
(destruction limit)
40 mA
• Accuracy
±1 %
• Input resistance
50 ohms
• Conversion time
150 ms
• Resolution
12 bits
• Open-circuit detection
For measuring range 4 mA to 20 mA
• Isolation of the inputs from
the device electronics
No
Outputs:
• Channels
1
• Parameterizable output
range
0/4 mA to 20 mA
• Cable shielding
Recommended for up to 30 m and outside the cabinet; shielding mandatory for cables
of 30 m or longer
