12.3.8 Modbus RTU connection to the SIMOCODE pro device
Connecting Modbus RTU to the SIMOCODE pro V Modbus basic unit
Modbus RTU can be connected to the SIMOCODE pro V basic unit both via the connecting
terminals as well as via the sub-D connector. The maximum data transfer rate for both
connection methods is 57,600 bps.
NOTICE
9-pin sub-D connection
The 9-way sub-D connection is an alternative to the A/B terminals!
Connecting Modbus RTU to the SIMOCODE pro V Modbus basic unit via the device terminals
Terminal assignment:
Terminal
Modbus signal
A
D0 or DA
B
D1 or DB
SPE
Cable shielding
Connecting Modbus RTU to the SIMOCODE pro V Modbus basic unit via the sub-D connector
The pin assignments of the 9-pin sub-D socket for SIMOCODE pro correspond to the
assignments defined for PROFIBUS DP. The sub-D connector has the following
assignments:
Pin
Modbus signal
8
D0 or DA
3
D1 or DB
5
Cable shielding
