Description of system components
8.13 Multifunction module
SIMOCODE pro
154 System Manual, 05/2019, A5E40507475002A/RS-AD/004
8.13 Multifunction module
The multifunction module is the expansion module of the SIMOCODE pro S device series
with the following functions:
● Digital module function with four digital inputs and two monostable relay outputs
● Ground-fault module function with one input for connecting a 3UL23 residual current
transformer
● Temperature module function with an input for connecting a PT100, PT1000, KTY83,
KTY84, or NTC analog temperature sensor
No more than one multifunction module can be connected to one
SIMOCODE pro S basic unit.
Note
Use of expansion modules of SIMOCODE pro V with the SIMOCODE pro S basic unit
One of the following expansion modules of SIMOCOD
E pro V can be used with the
pro S basic unit (3UF7020-1AB01-0 or 3UF7020-1AU01-0) instead of the
3UF76* multifunction module:
24 V DC digital module with monostable relay outputs (3UF7300-1AB00-0) or
110 ... 240 V AC/DC digital module (3UF7300-1AU00-0)
Ground-fault module (3UF7510-1AA0-0)
Temperature module (3UF7700-1AA00-0), limited to use of one sensor input only
